Track Class Reference

#include <Track.h>

Collaboration diagram for Track:

Public Member Functions
	Track (BeamSequence *, const PartData &, const std::vector< double > &dt, const std::vector< unsigned long long > &maxtsteps, int stepsperturn, double zStart, const std::vector< double > &zStop, Steppers::TimeIntegrator timeintegrator, double t0, double dtScInit, double deltaTau, EmissionSourceList *emissionSourcesList=nullptr, const std::vector< std::string > &beamNames={})
	~Track ()

Public Attributes
PartBunch_t *	bunch
	The particle bunch to be tracked.
PartData	reference
	The reference data.
BeamSequence *	use
	The lattice to be tracked through.
EmissionSourceList *	emissionSources
	The emission sources list for particle injection (SOURCES= on TRACK).
TrackParser	parser
	The parser used during tracking.
std::vector< double >	dT
	The initial timestep.
double	dtScInit
double	deltaTau
double	t0_m
std::vector< unsigned long long >	localTimeSteps
	Maximal number of timesteps.
int	stepsPerTurn
	The timsteps per revolution period. ONLY available for OPAL-cycl.
double	zstart
	The location at which the simulation starts.
std::vector< double >	zstop
	The location at which the simulation stops.
Steppers::TimeIntegrator	timeIntegrator
	The ID of time integrator.
int	truncOrder
	Trunction order for map tracking.
std::vector< std::string >	beamNames_m

Static Public Attributes
static Track *	block = 0
	The block of track data.

Private Member Functions
	Track ()
	Track (const Track &)
void	operator= (const Track &)

Static Private Attributes
static std::stack< Track * >	stashedTrack

Detailed Description

Definition at line 35 of file Track.h.

Constructor & Destructor Documentation

Track() [1/3]

Track::Track	(	BeamSequence *	u,
		const PartData &	ref,
		const std::vector< double > &	dt,
		const std::vector< unsigned long long > &	maxtsteps,
		int	stepsperturn,
		double	zStart,
		const std::vector< double > &	zStop,
		Steppers::TimeIntegrator	timeintegrator,
		double	t0,
		double	dtScInit,
		double	deltaTau,
		EmissionSourceList *	emissionSourcesList = nullptr,
		const std::vector< std::string > &	beamNames = {}
	)

Track is asking the dictionary if already a particle bunch was allocated. If that is the case Track is using the already allocated bunch, otherwise a new bunch is allocated in the dictionary.

Todo:

can we do this anymore OpalData::getInstance()->setPartBunch(new PartBunch(&ref));

Definition at line 36 of file Track.cpp.

References OpalData::getInstance().

Here is the call graph for this function:

~Track()

Track::~Track

(

)

Definition at line 66 of file Track.cpp.

Track() [2/3]

Track::Track ( )

private

Track() [3/3]

Track::Track ( const Track &  )

private

Member Function Documentation

operator=()

void Track::operator= ( const Track &  )

private

Member Data Documentation

beamNames_m

std::vector<std::string> Track::beamNames_m

The names of beams selected on the enclosing TRACK command. (If RUN::BEAM is omitted, TrackRun resolves from this list.)

Definition at line 92 of file Track.h.

Referenced by TrackRun::execute(), TrackRun::print(), and TrackRun::wireDaughterContainers().

block

Track * Track::block = 0

static

The block of track data.

Definition at line 60 of file Track.h.

Referenced by TrackCmd::execute(), TrackEnd::execute(), TrackRun::execute(), TrackRun::print(), and TrackRun::wireDaughterContainers().

bunch

PartBunch_t* Track::bunch

The particle bunch to be tracked.

Definition at line 45 of file Track.h.

deltaTau

double Track::deltaTau

Definition at line 66 of file Track.h.

dT

std::vector<double> Track::dT

The initial timestep.

Definition at line 63 of file Track.h.

Referenced by TrackRun::execute(), and TrackRun::print().

dtScInit

double Track::dtScInit

Definition at line 66 of file Track.h.

emissionSources

EmissionSourceList* Track::emissionSources

The emission sources list for particle injection (SOURCES= on TRACK).

Definition at line 54 of file Track.h.

localTimeSteps

std::vector<unsigned long long> Track::localTimeSteps

Maximal number of timesteps.

Definition at line 73 of file Track.h.

Referenced by TrackRun::execute(), and TrackRun::print().

parser

TrackParser Track::parser

The parser used during tracking.

Definition at line 57 of file Track.h.

Referenced by TrackCmd::execute(), and TrackEnd::execute().

reference

PartData Track::reference

The reference data.

Definition at line 48 of file Track.h.

stashedTrack

std::stack<Track*> Track::stashedTrack

staticprivate

Definition at line 100 of file Track.h.

stepsPerTurn

int Track::stepsPerTurn

The timsteps per revolution period. ONLY available for OPAL-cycl.

Definition at line 76 of file Track.h.

t0_m

double Track::t0_m

The ellapsed time of the beam can be used to propper start the beam when created in a cavity i.e. without emission

Definition at line 70 of file Track.h.

timeIntegrator

Steppers::TimeIntegrator Track::timeIntegrator

The ID of time integrator.

Definition at line 85 of file Track.h.

truncOrder

int Track::truncOrder

Trunction order for map tracking.

Definition at line 88 of file Track.h.

Referenced by TrackCmd::execute().

use

BeamSequence* Track::use

The lattice to be tracked through.

Definition at line 51 of file Track.h.

zstart

double Track::zstart

The location at which the simulation starts.

Definition at line 79 of file Track.h.

Referenced by TrackRun::execute().

zstop

std::vector<double> Track::zstop

The location at which the simulation stops.

Definition at line 82 of file Track.h.

Referenced by TrackRun::execute().

---

The documentation for this class was generated from the following files:

• Track.h
• Track.cpp
