MPIHelper.cpp File Reference

#include <cstddef>
#include <cstring>
#include <iomanip>
#include <limits>
#include <string>
#include "Util/MPIHelper.h"

Include dependency graph for MPIHelper.cpp:

Go to the source code of this file.

Functions
void	serialize (Param_t params, std::ostringstream &os)
	serializes params to a text stream, replaces boost::serialization
void	serialize (reqVarContainer_t reqvars, std::ostringstream &os)
void	deserialize (const char *buffer, std::size_t buf_size, Param_t &params)
void	deserialize (const char *buffer, std::size_t buf_size, reqVarContainer_t &reqvars)
void	MPI_Bcast_params (Param_t &params, std::size_t root, MPI_Comm comm)
	broadcast params to all entities in comm
void	MPI_Send_params (Param_t params, std::size_t pid, MPI_Comm comm)
std::pair< std::size_t *, char * >	MPI_ISend_params (Param_t params, std::size_t pid, MPI_Comm comm, MPI_Request *req)
void	MPI_Recv_params (Param_t &params, std::size_t pid, MPI_Comm comm)
void	MPI_Send_reqvars (reqVarContainer_t reqvars, std::size_t pid, MPI_Comm comm)
void	MPI_Recv_reqvars (reqVarContainer_t &reqvars, std::size_t pid, MPI_Comm comm)

Function Documentation

deserialize() [1/2]

void deserialize	(	const char *	buffer,
		std::size_t	buf_size,
		Param_t &	params
	)

deserializes params from an explicitly sized buffer (not null-terminated), replaces boost::serialization

Definition at line 68 of file MPIHelper.cpp.

Referenced by MPI_Bcast_params(), MPI_Recv_params(), MPI_Recv_reqvars(), and MPI_Recv_serialized().

deserialize() [2/2]

void deserialize	(	const char *	buffer,
		std::size_t	buf_size,
		reqVarContainer_t &	reqvars
	)

Definition at line 84 of file MPIHelper.cpp.

MPI_Bcast_params()

void MPI_Bcast_params	(	Param_t &	params,
		std::size_t	root,
		MPI_Comm	comm
	)

broadcast params to all entities in comm

Definition at line 100 of file MPIHelper.cpp.

References deserialize(), and serialize().

Referenced by Worker< Sim_t >::onMessage(), SampleWorker< Sim_t >::onMessage(), Worker< Sim_t >::runCoWorker(), and SampleWorker< Sim_t >::runSlave().

Here is the call graph for this function:

MPI_ISend_params()

std::pair< std::size_t *, char * > MPI_ISend_params	(	Param_t	params,
		std::size_t	pid,
		MPI_Comm	comm,
		MPI_Request *	req
	)

Serializes a parameter list and asynchronously sends (MPI) to another processor. The memory associated with returned buffers must be freed by the consumer.

Parameters

params	parameter list to serialize
pid	processor ID to send data to
comm	MPI communicator group used for sending the data
req	MPI request assigned with the ISend

Definition at line 144 of file MPIHelper.cpp.

References MPI_EXCHANGE_SERIALIZED_DATA_TAG, and serialize().

Here is the call graph for this function:

MPI_Recv_params()

void MPI_Recv_params	(	Param_t &	params,
		std::size_t	pid,
		MPI_Comm	comm
	)

Receives and unpacks a parameter list from another (MPI) processor.

Parameters

params	parameter list to store data
pid	processor ID to receive data from
comm	MPI communicator group used for receiving the data

Definition at line 166 of file MPIHelper.cpp.

References deserialize(), and MPI_EXCHANGE_SERIALIZED_DATA_TAG.

Referenced by Pilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::onMessage(), Worker< Sim_t >::onMessage(), SamplePilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::onMessage(), and SampleWorker< Sim_t >::onMessage().

Here is the call graph for this function:

MPI_Recv_reqvars()

void MPI_Recv_reqvars	(	reqVarContainer_t &	reqvars,
		std::size_t	pid,
		MPI_Comm	comm
	)

Receives and unpacks a required variable list from another (MPI) processor.

Parameters

reqvars	variable list to store data
pid	processor ID to receive data from
comm	MPI communicator group used for receiving the data

Definition at line 201 of file MPIHelper.cpp.

References deserialize(), and MPI_EXCHANGE_SERIALIZED_DATA_TAG.

Referenced by Sampler::onMessage(), Pilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::onMessage(), and SamplePilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::onMessage().

Here is the call graph for this function:

MPI_Send_params()

void MPI_Send_params	(	Param_t	params,
		std::size_t	pid,
		MPI_Comm	comm
	)

Serializes a parameter list and sends (MPI) to another processor.

Parameters

params	parameter list to serialize
pid	processor ID to send data to
comm	MPI communicator group used for sending the data

Definition at line 126 of file MPIHelper.cpp.

References MPI_EXCHANGE_SERIALIZED_DATA_TAG, and serialize().

Referenced by Sampler::dispatch_forward_solves(), Pilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::sendNewJobToWorker(), and SamplePilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::sendNewJobToWorker().

Here is the call graph for this function:

MPI_Send_reqvars()

void MPI_Send_reqvars	(	reqVarContainer_t	reqvars,
		std::size_t	pid,
		MPI_Comm	comm
	)

Serializes requested variable list and sends (MPI) to another processor.

Parameters

reqvars	variable list list to serialize
pid	processor ID to send data to
comm	MPI communicator group used for sending the data

Definition at line 183 of file MPIHelper.cpp.

References MPI_EXCHANGE_SERIALIZED_DATA_TAG, and serialize().

Referenced by Pilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::onMessage(), Worker< Sim_t >::onMessage(), SamplePilot< Opt_t, Sim_t, SolPropagationGraph_t, Comm_t >::onMessage(), and SampleWorker< Sim_t >::onMessage().

Here is the call graph for this function:

serialize() [1/2]

void serialize	(	Param_t	params,
		std::ostringstream &	os
	)

serializes params to a text stream, replaces boost::serialization

Definition at line 46 of file MPIHelper.cpp.

Referenced by AmrMultiGridLevel< MatrixType, VectorType >::buildMap(), AmrMultiGrid::buildRestrictionMatrix_m(), MPI_Bcast_params(), MPI_ISend_params(), MPI_Send_params(), MPI_Send_reqvars(), and MPI_Send_serialized().

serialize() [2/2]

void serialize	(	reqVarContainer_t	reqvars,
		std::ostringstream &	os
	)

Definition at line 57 of file MPIHelper.cpp.
